KLF01661 is a mower input front box, from which the power of the mower gearbox is derived. The input front box can simultaneously drive three mower gearboxes, offering a larger working width and advantages such as high efficiency.
KLF01661 is a mower input front box, from which the power of the mower gearbox is derived. The input front box can simultaneously drive three mower gearboxes, offering a larger working width and advantages such as high efficiency.
Speed Ratio i |
Modulu m |
Number of Teeth z |
Rated Power kW(hp) |
Input Speed rpm |
Output Speed rpm |
Input Torque N.m |
Output Torque N.m |
1:1.3 | 5.644 | 26/20 | 58.8(80) | 540 | 702 | 938 | 722 |
